Box 230 Kf2510-2 3 4 5P Male Female Jumper Connector Terminal Kit

Product information:
Model: 230 kf2510 in box
Type: Housing
Working frequency: low frequency
Application: power supply
Shape: Bar
Production process: cold pressing
Processing customization: Yes
Application field: household appliances

inventory
2pin = 10 pairs
3pin = 10 pairs
4Pin = 10 pairs
5pin = 10 pairs
Pin connector terminals: 150 (please allow 5% deviation)
Specifications:
Spacing: 2.54 mm
Rated current: 1aac, DC
Rated voltage: 125V AC, DC
Temperature range: - 25 ℃ to + 85 ℃
Insulation resistance: minimum 1009.
Withstand voltage: 500V AC / min
Wire range: AWG 24 32
Insulation outer diameter: 1.00mm (maximum)

Product volume
10.0cm * 6.6cm * 2.0 cm
